The SY6926QYC by Silergy Corporation is a robust solution for power management, designed with portable applications in mind. Its low-profile package, a QFN4x4, represents an optimal solution both in terms of compactness and efficiency. The incorporation of integrated N-Channel MOSFETs that have an 18V voltage rating and an incredibly low RDSON increase energy efficiency and system reliability. A high 1 MHz switching frequency helps further downsize and simplify the peripheral circuit design.
This innovative product boasts of features such as trickle current, as well as constant current and constant voltage charging modes. It can deliver a maximum of 5A battery charging current, which alongside a maximum of 2.5A Sys current in battery power supplement mode, ensures swift and safe power replenishment. Other noteworthy functionalities include automatic input power source detection, programmable SYS voltage, and over current limit for SYS load. It provides a charging mode CV tolerance of +/-0.5% and the CV voltage is selectable between 4.2V and 4.35V, adding layers of choice and control for users. Commodious programmability options and indicative features, such as programmable battery charging timeout and charge status indication, empower users to tweak settings as per their requirements and keep up-to-date with charging progress.
Silergy Corporation SY6926QYC Original Reel Label
SY6926QYC has found a niche in single-cell Li-Ion power banks and battery power path management. It demonstrates the rigour of Silergy's innovative approach to power solutions. Nantian Electronics, as an exemplary distributor of Silergy Corporation, provides ample stock of SY6926QYC, offering not only the product but also comprehensive support in the form of downloadable parameters, datasheets in PDF format, and detailed pin diagram instructions.
